Structural Shop Drawings – Post Tension Slab | Dammam, Kingdom of Saudi Arabia A detailed Post Tension Slab shop drawing package developed during the structural detailing phase, including: - Detailed Structural Layouts - Concrete Dimensions & Structural Details - Bottom Slab Mesh Reinforcement in X & Y Directions…

Structural Shop Drawings – Utility Tunnel FEEDCO Feed Mill & Grain Terminal Project | Kingdom of Saudi Arabia Completed the structural shop drawings package for the Utility Tunnel Facility, including: - Detailed Structural Layouts - Concrete Dimensions & Reinforcement Details - Reinforcement Sections - Bar Bendin…

Detailed Structural design Drawing for Scum Pumping Station at Saudi Arabia • Detailed structural layout • concrete dimension & Reinforcement sections • Design reports Below are snapshots from the drawing highlighting key structural details. #tanks #STP #saudiarabia #industrialbuilding #Structuraldesigndrawing #…

Access manhole opening shall be a minimum of 24 in(609.60mm). in diameter according to ASTM Standards

الكلاود دي لو قابلتك في قواعد المكن بالمشاريع الصناعية دي اسمها بوكت (Pocket) والشكل المموج ده بيزود مساحه التلامس بين الخرسانه اللي اتصبت والجراوت اللي هيجي يتصب بعدين مع الانكور وكمان معمول لزيادة التعشيق بين الخرسانه اللي اتصبت والجراوت ونقل الأحمال بكفاءة أعلى ويقاوم الانزلاق شكل فتحه البوكت لما نبصلها من…

Minimum Shrinkage and Temperature Reinforcement and Its Distribution Between Concrete Faces for Water-Containing Structures According to ACI 350.20 According to clause R12.13.2.6 In members with more than one layer of reinforcement, the shrinkage and temperature reinforcement is normally divided equally between bot…
